GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor

GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor

Product Details:

Place of Origin: Guangdong, China
Brand Name: Topshine/Neutral
Certification: ce, FCC
Model Number: CA02

Payment & Shipping Terms:

Price: $37.50/Sets 1-99 Sets
Packaging Details: Unit weight: 1Kg<br>Neutral color or white box<br>(12*8*3.5cm)
Get Best Price Contact Now

Detail Information

Model: B-series Year: 1983-
Type: GPS Tracker Placement: In-Dash 1DIN, In-Dash 2DIN
Car Fitment: FAP OS: No System
Screen Type: NO Resolution: 1280*720
Function: Vehicle GPS Tracking Combination: Vehicle GPS Tracking, Car Alarm, Central Locking System
Connection: 2G Sim Card Warranty: 2 Years
Use: Automotive GPS Tracker: Real Time GPS Tracking
Car Alarm: Built-in Car Alarm Rated Voltage: DC12V/DC24V
Over Speed: Over Speed Alarm Free GPS Tracking Software: Web Base/iOS Android APP
Central Locking System: Lock/unlock Via Remoter/APP/SMS Command Identify Jamming GSM Signal: Jamming GSM Signal Detection
Detect Acc: Engine On/off Status Movement: Movement Alert
Geofence: Geofence Alert
High Light:

Siren car security alarm

,

GSM car security alarm

,

Siren car security alarm system

Product Description

New Style Car Alarm Vehicle GPS Tracker with Siren Shock Sensor Relay Indicate Light
(Model : CA02 )
(2 years warranty, Free Tracking Platfrom   (Web base & Android APP )





 3 IN 1 Car Alarm+ GPS Tracker + Central lock


Hot Selling point :

1. Car alarm:
If somebody hit your car,CA02 will trigger siren ringing ( can choose send SMS alarm to your phone )

2. GPS tracking :
Real time tracking and monitoring your vehicle by computer or smartphone anytime anywhere

3. Central lock :
Unlock/lock car by Remoter/SMS/Computer/Smartphone

4. Identify jamming GSM signal :
If CA02 identify around have jamming device interfere the GSM signal ,will trigger relay to cut off engine/oil automatically.



GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor 0








GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor 2









GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor 4










2. Technical parameters



Shell Material ABS
Rated Voltage DC12V ±10%
Static Current 1.5A ±5%
Locked-rotor Current 4A-5A
Loading Current 2.5A ±5%
Push/Pull Force ≥3.5KG
Locked-rotor Time >20S
Operation Stroke 18mm±1
Active Time 0.26S-0.48S
Frequency >100cycles(50cycles/min)







3. Feature &Function





1. Real Time tracking vehicle
2. Car alarm
3. Central lock
4. Identify jamming GSM signal
5. Fuel monitoring ( optional )
6.Michel wiretapping ( optional )
7.SOS alarm ( optional )
8.Detect ACC status
9. Illegal open Door alarm
10.Cut off engine remotely
8. Manually trigger the Lock/unlock via remote control / tracking platform / APP / SMS command
11. Over speed alarm,
12.Geo fence alarm
13.Movement alarm
14.Siren alarm
15.Open trunk function
16.LED indicator light
17.Independent industry GSM/GPS module,Industrial grade CPU and Legal IMEI code
18.Free GPS tracking platform ( Web base and iOS Android App )








 GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor 6GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor 8










4. Standard test conditon

4.1 Temperature: -15 ºC~+35 ºC
4.2 Humidity: 25 % ~ 75 %


5. Operating condition

5.1 Temperature: -40 ºC~ +80 ºC
5.2 Humidity: ≤75%






6. Storage condition

6.1 Temperature: 0 ºC ~ 40 ºC
6.2 Humidity: 20% ~ 80 %
6.3 Environment
     (1) Store in locations where the product is not exposed to corrosive gas.
     (2) Keep product is not exposed to the direct ray of the sun.







GSM Siren Car Security Alarm system Vehicle GPS Tracker With Shock Sensor 10
