Product Details:

Place of Origin: CHINA
Brand Name: TOPSHINE
Certification: CE
Model Number: TSULS212

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: 1~80usd/pcs
Packaging Details: 23cm*12cm*5cm
Delivery Time: 2-7 works day
Payment Terms: Western Union, T/T, MoneyGram
Supply Ability: 10000pcs/month
Get Best Price Contact Now

Detail Information

Votlage: 12-24V Intstallation: No Drilling Holes In Tank, Easy Installation
Support Liquid: Diesel, Gasoline, Water, Etc Resolution: 2mm
Waterproof Grade: IP68
High Light:

BLE GPS Tracker Accessories

,

IP68 GPS Tracker Accessories

,

IP68 Ultrasonic Fuel Level Sensor

Product Description

Wireless BLE All-in-One Ultrasonic Fuel Level Sensor for Fleet Fuel Monitoring/Telematics

IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 0IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 1



Features & Specification:

  • No Drilling Holes in Tank, Easy Installation
  • Support Any Liquid: Diesel, Gasoline, Water, etc.
  • Support Any Material Tank: Metal/Aluminum/Stainless Steel /Fiber/Plastic
  • IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 2
  • Resolution: 0.1mm
  • Accuracy: 99.5%
  • Maximum Measuring Range: 100cm (TSULS212), 250cm (TSULS212-E)
  • Lowest Detection Hight(Blind Area): 3cm
  • Maximum Tank Thickness: 8~12mm
  • Output Interface: BLE Bluetooth 5.0 +RS232(Default)/RS485+Analog(0~5V)
  • Mobile App configuration & Calibration
  • Built-in AI Algorithm to filter abnormal signal
  • Fuel Theft Alarm I/O Output
  • IP68 waterproof
  • Hardware Partners: Teltonika, GEOTab, Calamp, Wireless Link, Queclink, Gosafe, Jimi Concox, Meitrack, Howen
Part No. Maximum Range Blind Area Beam Range

BLE

Bluetooth

Signal Output Voltage

UL212 100 cm 3cm 11° Yes RS232/RS485, Analogue (0~5V) 9~36V


UL212-E 250 cm 3cm 11° Yes RS232/RS485, Analogue (0~5V) 9~36V







IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 3













  1. Introduction
  • New Edge Bluetooth BLE All-in-One Ultrasonic Fuel Level sensor will use non-contact technology to detect fuel level without drilling holes.

With the ultrasonic reflection feature when cross liquid to air, it can read accurate fuel level height.

  • PPS(Phenylenesulfide) Plastic Housing, Anti-Corrosion/Strong Acid, Anti-Fire, and support Max300~400 300~400℃
  • Built-in BLE Bluetooth Module, Sync with RS232/RS485 & Analog output.
  • Fuel Theft Alarm & Refueling Alarm Output



  1. Electronic Specification
Parameter Description
Power Supply 9~36V DC
Max Power Consumption 0.7W @12V DC
Measuring Range 3~250cm
Resolution 0.1mm
Accuracy 99.5% (0# Diesel ,25℃)
Maximum Tank Thickness <12mm
Interface

RS232(default)/RS485

Analog 0~5V

BLE Bluetooth5.0

CAN (optional)

Serial Communication 9600 baud rate(customized),data bit 8, stop bit1, no flow control,no verification bit
Support Protocols Teltonika, GEOTAB, BCE, Ruptela, Ominicomm LLS, CR, Calamp, Atrack, Fifotrack, Queclink, Meitrack, Concox Jimi, Queclink, Xirgo,Wireless Link
Extension Cable 9 meters
Working Temperature -40~85℃ (@1 ATM)
Working Humid 5~99%
Explosion-proof Class Exd II CT5
Waterproof IP68









  1. Size

IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 4IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 5



  •
Power Supply 9~36V DC+
  •
Power GND, RS232/RS485 GND
  •
RS232 TX (Default), or RS485B Connect GPS/DVR RS232_RX, Or RS485B
  •
RS232 RX (Default), or RS485A Connect GPS/DVR RS232_TX, Or RS485B
  •
Analog Output 0~5V



  1. Approved M2M & DVR Brands:


Recommended GPS Tracker that can work with our ultrasonic fuel sensor:

  • VT1000
  • VT310N
  • MT100



  1. Part Number Serials with selectable protocol for Difference M2M GPS/DVR Hardware



1 Meter Version, TSULS212

Part Number Protocol Description/Complied Hardware
  •
  •
Baud Rate
  •
  1.

Standard Protocol:

Calamp,Atrack, Fifotrack, Wireless Link,etc.

  •
  •
  1.

RS232 or RS485

  1.

Analog 0~5V

  1.

  1.

Private Protocol with Fuel Theft I/O Alarm Output (Green Cable, 5V)

  •
  •
  1.

RS232 or RS485

  1.
  1.
Support Fuel Theft Alarm
  1.

Private Protocol with Volume & Height Output at the same time, with Fuel Theft I/O Alarm Output (Green Cable , 5V)

  •
  •
  1.

RS232 or RS485

  1.
  1.
  1. 0027 Indicates 2.7L for volume
  2. Support Fuel Theft Alarm
  1.
  •
  •
  •
  1.

RS232 or RS485

  1.

Analog 0~5V

  1.

  1.

Omonicomm LLS protocol, Eurosens,

  •

Example: 3E 01 07 14 DC 04 DC 04 67

  1.

RS232 or RS485

  1.

Analog 0~5V

  1.
Net Address 1
  1.
  •
  1.

RS232 or RS485

  1.

Analog 0~5V

  1.
Net Address 2
  1.
  •
  1.

RS232 or RS485

  1.

Analog 0~5V

  1.
Net Address 1
  1.
GEOTAB
  1.
  1.
  2.

Analog 0~5V

  1.
Programmable Full Tank Height
  1.

CR Protocol: Icarvision, BSJ

  •

*CFV01001A3DF3

  1.
  1.
  1.
Net Address 1
  1.
Modbus Protocol
  1.

RS232 or RS485

  1.

  1.
  •
  1.
  1.
  2.

Analog 0~5V

  1.
Net Address 1



2.5 Meter Version, TSULS212-E

Please refer to our sales team and tech support for related Part Number.





  1. Mobile APP via BLE connection

IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 6IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 7IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 8IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 9 IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 10 IP68 Waterproof GPS Tracker Accessories Wireless BLE Ultrasonic Fuel Level Sensor 11
